Finally got my Sky TBB results to work, the large green spike was when I had my PS3 on downloading a demo from PSN, plus 2 laptops running constantly just browsing.
Also bear in mind there appears to be a fault on my line (noise I suspect), which is yet to be rectified, but either way it's not looking brilliant.
I appreciate this is deviating from the topic but could anyone comment on my router stats,
ROUTER STATISTICS
System Up Time: 5:11:04
Port Status TxPkts RxPkts Collisions Tx B/s Rx B/s Up Time
WAN PPPoA 421460 792459 0 26344972 1133512130 5:10:01
LAN Down 0 0 0 0 0 5:11:04
WLAN Up 179284 164847 0 50559423 13928571 5:10:45
ADSL Link Downstream Upstream
Connection Speed 3488 kbps 800 kbps
Line Attenuation 56.0 dB 31.5 dB
Noise Margin 11.2 dB 11.0 dB
I've been next door to my neighbour and obtained his Sky router stats and his downstream speed is damn near double mine.
His router stats
Connection Speed (down=6713kbps) and (Up=796kbps)
Line attenuation (down=49db) and (Up=26.4db)
Noise Margin (down=6.6db) and (Up=15.5)
Nextdoor's router stats are world's apart from mine, the only thing is I have absolutely no idea what it means.
Any comment's from our more knowledgeable gentry
