50M : Think Broadband Ping Monitor Results (POST YOURS)

[Martin_D]

Originally Posted by Jumping

WUUT!? I'm still on 5 grrr, and looking at my graphs I seem to get STMed really easy and it proper kills my upload speed in the evening.

Your UBR must not need more capacity yet.

Lets hope they get the upstream bonding done soon

[Jumping]

Well it probably doesn't as without STM I have never had any issues getting good speeds.

How ever the STM really seem to hit harder than it should and I'm already miffed that the speed doubling didn't double the upload speed until the 120mb upgrade has been done.

I just can't see myself staying with Virgin for long once FTTC has been rolled out in Wishaw.

Was looking back to the the last two days worth of graphs and its amazing how much the blue shots up in the graph when the STM hits and I did some brief speed tests last night and my upload speed was sub 1mbit from all the sites I tried and latency was much higher than usual even from the trusty Preston speedtest site which gives me constant low latency even better than the new Virgin hosted Glasgow site.

It's so bad that even facebook gaming is affected and really slow at loading.

[weegiegeek]

6 downstreams here in Rutherglen.

[Martin_D]

I don't download a lot so i don't get STM so my broadband speed is ok most of the time :p

http://www.speedtest.net/result/2714823431.png

[Martin_D]

I just lost 7 Downstreams

Attachment 24549

http://www.speedtest.net/result/2725263943.png

Got the 7 back from doing a reboot

[Martin_D]

Just lost internet for about 2 mins :/

Network Log
First Time Last Time Priority Error Number Description
22/05/2013 21:27:40 GMT 22/05/2013 21:27:40 GMT Error (4) 69010700 SW upgrade Failed after download - Incompatible SW file
22/05/2013 21:26:30 GMT 22/05/2013 21:26:30 GMT Notice (6) 69010200 SW Download INIT - Via Config file 9834ncxv9873254k;fg8
22/05/2013 21:26:28 GMT 22/05/2013 21:26:28 GMT Error (4) 68000407 TOD established
22/05/2013 21:26:17 GMT 22/05/2013 21:26:17 GMT Critical (3) 82000200 No Ranging Response received - T3 time-out
22/05/2013 21:26:10 GMT 22/05/2013 21:26:10 GMT Notice (6) 84000510 Downstream Locked Successfully
22/05/2013 21:26:01 GMT 22/05/2013 21:26:01 GMT Error (4) 68000407 TOD established
22/05/2013 21:25:49 GMT 22/05/2013 21:25:49 GMT Critical (3) 82000200 No Ranging Response received - T3 time-out
22/05/2013 21:25:33 GMT 22/05/2013 21:25:33 GMT Notice (6) 84000510 Downstream Locked Successfully
22/05/2013 21:25:33 GMT 22/05/2013 21:25:33 GMT Warning (5) 84020300 MDD message timeout
22/05/2013 21:25:33 GMT 22/05/2013 21:25:33 GMT Warning (5) 84020200 Lost MDD Timeout
22/05/2013 21:25:18 GMT 22/05/2013 21:25:18 GMT Critical (3) 82000200 No Ranging Response received - T3 time-out
22/05/2013 21:25:15 GMT 22/05/2013 21:25:15 GMT Critical (3) 82000400 Received Response to Broadcast Maintenance Request, But no Unicast Maintenance opportunities received - T4 time out
22/05/2013 21:25:01 GMT 22/05/2013 21:25:01 GMT Critical (3) 84000500 SYNC Timing Synchronization failure - Loss of Sync
22/05/2013 21:24:56 GMT 22/05/2013 21:24:56 GMT Critical (3) 82000200 No Ranging Response received - T3 time-out
22/05/2013 21:24:55 GMT 22/05/2013 21:24:55 GMT Critical (3) 84000500 SYNC Timing Synchronization failure - Loss of Sync
22/05/2013 21:24:46 GMT 22/05/2013 21:24:46 GMT Critical (3) 84000500 SYNC Timing Synchronization failure - Loss of Sync
22/05/2013 21:24:39 GMT 22/05/2013 21:24:39 GMT Notice (6) 84000510 Downstream Locked Successfully
22/05/2013 21:24:38 GMT 22/05/2013 21:24:38 GMT Warning (5) 84020300 MDD message timeout
22/05/2013 21:24:38 GMT 22/05/2013 21:24:38 GMT Warning (5) 84020200 Lost MDD Timeout
22/05/2013 21:24:25 GMT 22/05/2013 21:24:25 GMT Critical (3) 84000500 SYNC Timing Synchronization failure - Loss of Sync

[roughbeast]

Interesting goings on in CV3



The first red line is not me, but the 2nd and 3rd are me rebooting SH2. Still on 6 channels down and 1 up. We are due to be on 120Mb by the end of May. I know that CV1, student land, has been suffering from congestion and were due for a fix, resegmenting etc, by 22nd. May.

[Martin_D]

15 hours without internet

[Kushan]

At least most of those 15 hours were at night.

[joeron]

Net was on and off, on wednesday when it come back on noted it now has 2 upstream channel's one of the channel keep changing mode from QAM 16 to qpsk, tho this does not seem to cause a problem, i see dot of red but im not sure if this is link as im seeing this on a lot of graph.





Upstream US-1 US-2 US-3 US-4
Channel Type 2.0 2.0 N/A N/A
Channel ID 3 1 N/A N/A
Frequency (Hz) 27400000 Hz 45800000 Hz N/A N/A
Ranging Status Success Success N/A N/A
Modulation Qpsk QAM16 N/A N/A
Symbol Rate (Sym/sec) 5120000 5120000 N/A N/A
Mini-Slot Size 128 128 N/A N/A
Power Level (dBmV) 40.3 dBmV 40.5 dBmV N/A N/A
T1 Timeouts 0 0 N/A N/A
T2 Timeouts 0 0 N/A N/A
T3 Timeouts 0 0 N/A N/A
T4 Timeouts 0 0 N/A N/A


DS-1 DS-2 DS-3 DS-4 DS-5 DS-6 DS-7 DS-8
Frequency (Hz) 291000000 Hz 299000000 Hz 307000000 Hz 315000000 Hz 323000000 Hz N/A N/A N/A
Lock Status(QAM Lock/FEC Sync/MPEG Lock) Locked Locked Locked Locked Locked N/A N/A N/A
Channel ID 1 2 3 4 5 N/A N/A N/A
Modulation QAM256 QAM256 QAM256 QAM256 QAM256 N/A N/A N/A
Symbol Rate (Msym/sec) 6.952000 6.952000 6.952000 6.952000 6.952000 N/A N/A N/A
Interleave Depth I=12
J=17 I=12
J=17 I=12
J=17 I=12
J=17 I=12
J=17 N/A N/A N/A
Power Level (dBmV) 0.8 dBmV 0.6 dBmV 0.5 dBmV 0.5 dBmV 0.5 dBmV N/A N/A N/A
RxMER (dB) 41.4 dB 41.4 dB 41.5 dB 41.4 dB 41.9 dB N/A N/A N/A

[Sephiroth]

SH2 in router mode. Been like this for weeks.

[craigj2k12]

Looks like the SH1 is better on latency, any idea why, I thought someone mentioned they ran the same firmware?

[weegiegeek]

Originally Posted by craigj2k12

Looks like the SH1 is better on latency, any idea why, I thought someone mentioned they ran the same firmware?

What are you basing that observation on?

[Sephiroth]

Originally Posted by craigj2k12

Looks like the SH1 is better on latency, any idea why, I thought someone mentioned they ran the same firmware?

They don't run the same firmware because the DOCSIS chip drivers have to be different.

I get the same latency in router mode as a did on the SH1 when I did some pre-SH2 tests.

BUT ... in the early part of the trial I was getting high jitter. You can see in the attached picture towards the left there is the modem mode bathtub, then router mode, then a short modem mode bathtub, then router mode and a sudden and so far permanent drop in jitter whilst in router mode.

[weegiegeek]

Still 6 downstreams, 2 upstreams here and no sign of the 120mbit profile. 6 days to go...

Edit: Sonofa... We estimate your area will be ready between July 2013 and September 2013.

Nice of them to notify us of their change. I guess I shouldn't be surprised.
